Pipe Fitting

• Application
• other, Pipeline, Water Supply, Gas, Oil, Chemical Industries

• Coating Type
• No Coating / Natural Finish

• Color
• Metallic Silver

• Connection
• Other, Welded / Socket Weld / Threaded

• Connection Type
• Butt Weld / Threaded / Socket Weld

• Diameter
• As per requirement

• Flexibility
• Rigid

• Length
• Standard or As Required

• Material
• Stainless Steel

• Material Grade
• 304 / 304L / 316 / 316L

• Outer Diameter
• 1/2 to 24 (customizable)

• Product Type
• Other, Pipe Tee

• Rated Pressure
• Up to 6000 PSI

• Sealing Type
• Metal to Metal

• Section Shape
• Round

• Shape
• Other, Tee

• Standard
• Other, ASTM A403 / ASME SA403

• Surface Treatment
• Other, Polished / Pickled

• Temperature Range
• -20C to 300C

• Tensile Strength
• 515 MPa min (for 304/316)

• Thickness
• 2 mm to 20 mm (varies by spec)

• Thread Type
• BSP / NPT (if threaded)

• Tolerance
• 0.1 mm

• Usage
• Pipe Fitting Connection

• Yield Strength
• 205 MPa min (for 304/316)

• Application
• other, Oil & Gas, Petrochemical, Food Industry, Water Supply

• Bend Radius
• 1.5D / 2D / Custom

• Coating Type
• Uncoated / As required

• Color
• Silver / Metallic

• Connection
• Other, Butt Weld / Socket Weld / Threaded

• Connection Type
• Welded / Threaded

• Diameter
• Available in multiple sizes (e.g., 21.3mm - 609.6mm)

• Flexibility
• Rigid

• Length
• According to ASME/ANSI Standard or Custom

• Material
• Stainless Steel

• Material Grade
• SS304 / SS316 / SS316L / SS321 / SS347

• Outer Diameter
• 1/2 inch to 24 inch

• Product Type
• Other, Elbow Fitting

• Rated Pressure
• PN6 / PN16 / Sch40 / Sch80

• Sealing Type
• Metal to Metal

• Section Shape
• Round

• Shape
• Other, Elbow (Curved)

• Standard
• Other, ASTM A403 / ASME B16.9

• Surface Treatment
• Other, Polished / Shot Blasted

• Temperature Range
• -20C to 450C

• Tensile Strength
• 520 MPa minimum (for SS304)

• Thickness
• Schedule 10/20/40/80 (Customizable)

• Thread Type
• BSP / NPT (for threaded types)

• Tolerance
• 0.1 mm

• Usage
• Pipe Connection / Plumbing / Industrial Fluid Transfer

• Yield Strength
• 205 MPa minimum (for SS304)

• Application
• other, Oil & Gas, Water Supply, Chemical Industry, Power Plant, Construction

• Bend Radius
• 1.5D, 3D or Custom

• Coating Type
• Galvanized, Epoxy, Painted, None

• Color
• Silver / Metallic Grey

• Connection
• Other, Butt Weld / Socket Weld / Threaded

• Connection Type
• Buttweld, Socket Weld, Threaded

• Diameter
• As specified / Customizable

• Flexibility
• Rigid

• Length
• Custom As Per Requirement

• Material
• Other , Stainless Steel / Carbon Steel / Alloy Steel

• Material Grade
• 304 / 304L / 316 / 316L / A234 WPB / A420 WPL6

• Outer Diameter
• 1/2 to 48 (DN15-DN1200)

• Product Type
• Other, Steel Pipe Elbow

• Rated Pressure
• Up to 40 Bar or As per Specification

• Sealing Type
• Metal to Metal

• Section Shape
• Round

• Shape
• Other, Elbow, Tee, Reducer

• Standard
• Other, ASTM A403 / ASME B16.9 / DIN / JIS / EN

• Surface Treatment
• Other, Polished / Sand Blasted / Pickled

• Temperature Range
• -20C to +600C

• Tensile Strength
• 480 MPa min (typical for stainless steel grades)

• Thickness
• Sch 10, Sch 20, Sch 40, Sch 80, Custom as required

• Thread Type
• NPT, BSPT, BSP, As Required

• Tolerance
• 1% or as per standard specifications

• Usage
• Industrial Pipe Fitting / Plumbing

• Yield Strength
• 205 MPa min (typical for stainless steel grades)

• Application
• other, Pipeline Transportation, Water Supply, Gas, Oil

• Coating Type
• Uncoated / Self Finish

• Color
• Silver / Metallic

• Connection
• Other, Butt Weld

• Connection Type
• Welded

• Diameter
• As per customer specifications

• Flexibility
• Rigid

• Length
• Customized

• Material
• Stainless Steel

• Material Grade
• 304 / 304L / 316 / 316L

• Outer Diameter
• 1/2 to 24 (DN15 - DN600)

• Product Type
• Other, Pipe Fitting Tee

• Rated Pressure
• Up to 6000 PSI

• Sealing Type
• Metal to Metal

• Section Shape
• Round

• Shape
• Other, Tee

• Standard
• Other, ASTM A403 / ASME B16.9

• Surface Treatment
• Other, Polished

• Temperature Range
• -20C to 850C

• Tensile Strength
• 515 - 620 MPa

• Thickness
• Sch10 / Sch20 / Sch40 / Sch80 or customized

• Tolerance
• 0.1 mm

• Usage
• Industrial, Plumbing, Chemical, Petrochemical

• Yield Strength
• 205 - 310 MPa
